产品简述：

绵阳市维博电子有限责任公司是中国兵器装备集团自动化研究所控股的高新技术企业，主要从事电量隔离传感器、智能电量变送器、控制及驱动器、辐射监测产品、各种检测仪表等产品的研发、生产与销售。公司推出的WB系列电量隔离传感器诞生于1989年，在公司的带领和推动下，全国已形成了一个新兴的模块化隔离检测行业。公司是《电量隔离传感器》、《物联网电流变送器规范》国家标准主草单位，于2021年成功入选工信部“专精特新小巨人”企业。

A. 电流隔离传感器

交流电流传感器

型号输入输出电源
WBI411D47AC 0.5A, 1A, 2A……8AAC 0~3.5V, 0~5VDC ±12V, ±15V
WBI412D41AC 0.5A, 1A, 2A……8ADC 0~5VDC +12V, +15V
WBI412H29AC 0.1A, 0.5A, 1A……5ADC 0~5V, 0~10V, 1~5VAC/DC 85V~265V
WBI414H29AC 0.1A, 0.5A, 1A……5ADC 0~20mA, 4~20mAAC/DC 85V~265V
WBI412M05AC 0.5A, 1A, 2A……5ADC 0~5V, 0~10V,  1~5VDC 9V~36V
WBI414M05AC 0.5A, 1A, 2A……5ADC 0~20mA, 4~20mADC 9V~36V
WBI411N95AC 0.5A~30AAC 0~3.5V, 0~5VDC 9V~36V
WBI411N97AC 0.5A~30AAC 0~3.5V, 0~5VDC ±12V, ±15V
WBI412N91AC 0.5A~30ADC 0~5V, 0~10V, 1~5VDC +12V, +15V, +24V
WBI412N95AC 0.5A~30ADC 0~5V, 0~10V, 1~5VDC 9V~36V
WBI414N91AC 0.5A~30ADC 0~20mA, 4~20mADC +12V, +15V, +24V
WBI414N95AC 0.5A~30ADC 0~20mA, 4~20mADC 9V~36V
WBI411N25AC 30A, 50A, 80A……400AAC 0~3.5V, 0~5VDC 9V~36V
WBI411N27AC 30A, 50A, 80A……400AAC 0~3.5V, 0~5VDC ±12V,  ±15V
WBI412N21AC 30A, 50A, 80A……400ADC 0~5V, 0~10V, 1~5VDC +12V, +15V, +24V
WBI412N25AC 30A, 50A, 80A……400ADC 0~5V, 0~10V, 1~5VDC 9V~36V
WBI414N21AC 30A, 50A, 80A……400ADC 0~20mA, 4~20mADC +12V, +15V, +24V
WBI414N25AC 30A, 50A, 80A……400ADC 0~20mA, 4~20mADC 9V~36V
WBI412F31AC 50A, 80A, 100A……500ADC 0~5V, 0~10VDC +12V, +24V
WBI414F23AC 30A, 50A,  80A……400ADC 4~20mADC +12V, +24V
WBI414F31AC 50A, 80A, 100A……500ADC 0~20mA, 4~20mADC +12V, +24V
WBI414F33AC 50A, 80A, 100A……500ADC 4~20mADC +12V, +24V
WBI414F41AC 50A, 80A, 100A……500ADC 0~20mA, 4~20mADC +12V, +24V
WBI414F43AC 50A, 80A, 100A……500ADC 4~20mADC +12V, +24V
WB3I414U31AC 0-5A, 量程可定制DC 0~20mA, 4~20mADC +12V, +24V
WBI412F21AC 30A, 50A, 80A……400ADC 0~5V, 0~10VDC +12V, +24V
WBI412F41 AC 50A, 80A, 100A……500ADC 0~5V, 0~10V, 1 ~5VDC +12V, +24V
WBI412M01AC 0.5A, 1A, 2A……5ADC 0~5V, 0~10V, 1 ~5VDC +12V, +24V
WBI414M01AC 0.5A, 1A, 2A……5ADC 0~20mA, 4~20mADC +12V, +24V
WBI412S01 AC 0.5A, 1A, 2A……5ADC 0~5V, 0~10V, 1~5VDC +12V, +24V
WBI412S41AC 0.5A, 1A, 2A……8ADC 0~5V, 0~10V, 1~5VDC +12V, +24V
WBI412S91AC 5A, 8A, 10A, 30A, 40A, 50ADC 0~5V, 0~10V, 1~5VDC +12V, +24V
WBI414F21AC 30A, 50A, 80A……400ADC 0~20mA, 4~20mADC +12V, +24V
WBI414S01AC 0.5A, 1A, 2A……5ADC 0~20mA, 4~20mADC +12V, +24V
WBI414S03AC 0.5A, 1A, 2A……5ADC 4~20mADC +12V, +24V
WBI414S05AC 0.5A, 1A, 2A……5ADC 0~20mA, 4~20mADC +12V, +24V
WBI414S41AC 0.5A, 1A, 2A……8ADC 0~20mA, 4~20mADC +12V, +24V
WBI414S91AC 5A, 8A, 10A, 30A, 40A, 50ADC 0~20mA, 4~20mADC +12V, +24V
WBI414S93AC 5A, 8A, 10A, 30A, 40A, 50ADC 4~20mADC +12V, +24V
WBI414S95AC 5A, 8A, 10A, 30A, 40A, 50ADC 0~20mA, 4~20mADC +12V, +24V
WBI414U01AC 0.5A, 1A, 2A……5ADC 0~20mA, 4~20mADC +12V, +24V
WBI414U09AC 0.5A, 1A, 2A……5ADC 0~20mA, 4~20mAAC/DC 85V~265V

直流电流传感器

型号输入输出电源
WBI342U01-SDC 1mA, 5mA, 20mA…5ADC 0~5V, 0~10VDC +12V, +24V
WBI342U05-SDC 1mA, 5mA, 20mA…5ADC 0~5V, 0~10VDC +12V, +24V
WBI344U01-SDC 1mA, 5mA, 20mA…5ADC 0~20mA, 4~20mADC +12V, +24V
WBI344U05-SDC 1mA, 5mA, 20mA…5ADC 0~20mA, 4~20mADC +12V, +24V
WBI332U01-SDC 1mA, 5mA, 20mA…5ADC 0~5V, 0~10VDC +12V, +24V
WBI332U05-SDC 1mA, 5mA, 20mA…5ADC 0~5V, 0~10VDC +12V, +24V
WBI334U01-SDC 1mA, 5mA, 20mA…5ADC 0~20mA, 4~20mADC +12V, +24V
WBI334U05-SDC 1mA, 5mA, 20mA…5ADC 0~20mA, 4~20mADC +12V, +24V
WBI132G31DC 1mA, 5mA, 20mA…5ADC 3V, DC3.5V, DC5V, DC10VDC+5V, +12V, +15V, +24V
WBI141G31DC 1mA, 5mA, 20mA…5ADC 3V, DC3.5V, DC5V, DC10VDC+5V, +12V, +15V, +24V
WBI151G31DC 1mA, 5mA, 20mA…5ADC 1.25V±1.25V, DC 2.5V±2.5V,DC 5V±5VDC+5V, +12V, +15V, +24V
WBI332H29DC 1mA, 5mA, 20mA…5A; 外置分流器可扩展DC 0~5V, 0~10VAC/DC 85V~265V
WBI342H29DC 1mA, 5mA, 20mA…5A; 外置分流器可扩展DC 0~5V, 0~10VAC/DC 85V~265V
WBI334H29DC 1mA, 5mA, 20mA…5A; 外置分流器可扩展DC 0~20mA, 4~20mAAC/DC 85V~265V
WBI344H29DC 1mA, 5mA, 20mA…5A; 外置分流器可扩展DC 0~20mA, 4~20mAAC/DC 85V~265V

交直流电流传感器（通用型）

型号输入输出电源
WBI121S07AC/DC 1mA, 5mA, 20mA…5AAC/DC 0~3.5V, 0~5VDC ± 12V, ±15V
WBI122S01AC/DC 1mA, 5mA, 20mA…5ADC 0~5V, 0~10VDC +12V, +24V
WBI124S01AC/DC 1mA, 5mA, 20mA…5ADC 0~20mA, 4~20mADC +12V, +24V
WBI125S01AC/DC 1mA, 5mA, 20mA…5ADC 0~5V, 0~10VDC +12V, +24V
WBI127S01AC/DC 1mA, 5mA, 20mA…5ADC 0~20mA, 4~20mADC +12V, +24V
WBI121G37AC/DC 1mA, 5mA, 20mA…5AAC/DC 0~3.5V, 0~5VDC ± 12V, ±15V

漏电流传感器

型号输入输出电源
WBL411F27AC 10mA, 30mA, 100mA…500mAAC 0~3.5V, 0~5VDC ±12V, ±15V
WBL412F21AC 10mA, 30mA, 100mA…500mADC 0~5VDC +12V, +24V
WBL551F27±DC 20mA, 50mA…300mADC 0±5VDC ±12V, ±15V
WBL551F47 ±DC 20mA, 50mA…300mADC 0±5VDC ±12V, ±15V
WBL551AT03-20(小)±DC 10mA, 50mA…5ADC 0±2.5V, 0±5VDC ±12V, ±15V
WBL414F21AC 10mA, 30mA, 100mA…500mADC 0~20mA, 4~20mADC +12V, +24V

B. 霍尔电流传感器

元件型霍尔电流传感器

型号输入输出电源
WBI021TK02-3AC/DC 6A……50AAC/DC 2.5V±0.625VDC +5V
WBI023TK02-3AC/DC 25A……50AAC/DC 25mADC ±12V, ±15V
WBI021TK02-8±DC 10A……100AAC/DC 2.5V±1VDC +5V
WBI023TK02-8AC/DC 25A……100AAC/DC 25mA, 50mA, 75mADC ±12V, ±15V
WBI021TK01-P±DC 5A……30AAC/DC 2.5V±0.625VDC +5V
WBI021QN01-ZAC/DC 3A……50AAC/DC 4VDC ±12V, ±15V
WBI021QN01AC/DC 5A……75AAC/DC 4VDC ±12V, ±15V
WBI221TK02-16AC/DC 50A……300AAC/DC 4VDC ±12V, ±15V
WBI023TK02-AAC/DC 25A……200AAC/DC 25mA, 50mA, 50mA, 100mADC ±12V, ±15V
WBV023TK01AC/DC 5mA, 10mA（外加电阻）AC/DC 25mADC ±12V, ±15V
WBI023JB7AC/DC 30AAC/DC 15mA, 20mA, 100mADC ±12V, ±15V

开启式霍尔电流传感器

型号输入输出电源
WBI221LY05-25AC/DC 50A……400AAC/DC 5VDC ±12V, ±15V
WBI222LY05-25AC/DC 50A……400ADC 0~5VDC +12V, +24V
WBI224LY05-25AC/DC 50A……400ADC 4~20mADC +12V, +24V
WBI222LY05-38AC/DC 300A……800ADC 0~5VDC +12V, +24V
WBI021JA7AC/DC 50A, 100AAC/DC 5VDC ±12V, ±15V
WBI024JA1AC/DC 50A, 100ADC 0~20mA, 4~20mADC +12V, +15V, +24V
WBI053J21±DC 50A, 100ADC 12mA±8mADC +12V, +15V, +24V
WBI221QN05-20AC/DC 100A……500AAC/DC 4V, 5VDC ±12V, ±15V
WBI221QN05-40AC/DC 400A……2000AAC/DC 4V, 5VDC ±12V, ±15V
WBI221QN05-J1AC/DC 400A……2000AAC/DC 4V, 5VDC ±12V, ±15V

闭环式霍尔电流传感器

型号输入输出电源
WBI021F27AC/DC 20A……100AAC/DC 3.5V, 4V, 5VDC ±12V, ±15V
WBI023F27AC/DC 20A……100AAC/DC 10mA……50mADC ±12V, ±15V
WBI022F21AC/DC 20A……100ADC 0~5V, 0~10V, 1~5VDC +12V, +15V, +24V
WBI024F21AC/DC 20A……100ADC 0~20mA, 4~20mADC +12V, +15V, +24V
WBI051F21± DC 20A……100ADC 2.5V± 1.25V, 5V±2.5V, 5V±5V, 2.5V±2.5VDC +12V, +15V, +24V
WBI053F21± DC 20A……100ADC 12mA±8mA, 10mA±10mADC +12V, +15V, +24V
WBI221F27AC/DC 100A……300AAC/DC 3.5V, 4V, 5VDC ±12V, ±15V
WBI222F21AC/DC 100A……300ADC 0~5V, 0~10V, 1~5VDC +12V, +24V
WBI224F21AC/DC 100A……300ADC 0~20mA, 4~20mADC +12V, +24V
WBI221F47AC/DC 200A……600AAC/DC 3.5V, 4V, 5VDC ±12V, ±15V
WBI222F41AC/DC 200A……600ADC 0~5V, 0~10V, 1~5VDC +12V, +24V
WBI224F41AC/DC 200A……600ADC 0~20mA, 4-20mADC +12V, +24V
WBI251F21±DC 100A……300ADC 5V±5V, 2.5V±2.5VDC +12V, +24V
WBI023TK03-20AC/DC 100A……300AAC/DC 50mA, 100mA, 150mADC ±12V, ±15V
WBI023TK03-35AC/DC 300A……500AAC/DC 100mADC ±12V, ±15V
WBI221JC03-B±DC 50A~600ADC 2.5V±0.5V, 25V±125V, 2.5V/±2VDC +5V
WBI221TK03-BAC/DC 50A……600AAC/DC 4V, 5VDC ±12V, ±15V
WBI221JC03-CAC/DC 100A~2000AAC/DC 4VDC ±12V, ±15V

高精度霍尔电流传感器

型号输入输出电源
WBI023TK03-40-0.1AC/DC 10A……1000AAC/DC 2mA……200mADC ±12V, ±15V, ±24V
WBI023TK03-20-0.2AC/DC 100A……300AAC/DC 50mA……100mADC ±12V, ±15V, ±24V

C. 电压隔离传感器

交流电压传感器

型号输入输出电源
WBV411D07AC 10V, 50V, 100V……1000VAC 0~3.5V, 0~5VDC ±12V, ±15V
WBV412D01AC 10V, 50V, 100V……1000VDC 0~5VDC +12V, +15V
WBV412H29AC 10V, 50V, 100V……500VDC 0~5V, 0~10V, 1~5VAC/DC 85V~265V
WBV414H29AC 10V, 50V, 100V……500VDC 0~20mA, 4~20mAAC/DC 85V~265V
WBV412M05AC 10V, 50V, 100V……1000VDC 0~5V, 0~10V, 1~5VDC 9V~36V
WBV414M05AC 10V, 50V, 100V……1000VDC 0~20mA, 4~20mADC 9V~36V
WB3U412U01AC 10V, 50V, 100V……500VDC 0~5VDC +12V, +24V
WB3U414U01AC 10V, 50V, 100V……500VDC 0~20mA, 4~20mADC +12V, +24V
WB3V412U01AC 10V, 50V, 100V……500VDC 0~5V, 0~10VDC +12V, +24V
WB3V414U01AC 10V, 50V, 100V……500VDC 0~20mA, 4~20mADC +12V, +24V
WBV112S01AC 10V, 50V, 100V……1000VDC 0~5V, 0~10V, 1~5VDC +12V, +24V
WBV412S01AC 10V, 50V, 100V……1000VDC 0~5V, 0~10V, 1~5VDC +12V, +24V
WBV412M01AC 10V, 50V, 100V……1000VDC 0~5V, 0~10V, 1~5VDC 9V~36V
WBV414M01AC 10V, 50V, 100V……1000VDC 0~20mA, 4~20mADC 9V~36V
WBV412U01AC 10V, 50V, 100V……1000VDC 0~5V, 0~10VDC +12V, +24V
WBV414U01AC 10V, 50V, 100V……1000VDC 0~20mA, 4~20mADC +12V, +24V

直流电压传感器

型号输入输出电源
WBV342U01-S直流DC 10mV, 10V, 100V, 500V, 1000VDC 0~5V, 0~10VDC +12V, +24V
WBV342U05-S直流DC 10mV, 10V, 100V, 500V, 1000VDC 0~5V, 0~10VDC +12V, +24V
WBV344U01-S直流DC 10mV, 10V, 100V, 500V, 1000VDC 0~20mA, 4~20mADC +12V, +24V
WBV344U05-S直流DC 10mV, 10V, 100V, 500V, 1000VDC 0~20mA, 4~20mADC +12V, +24V
WBV332U01-S脉动直流DC 10mV, 10V, 100V, 500V, 1000VDC 0~5V, 0~10VDC +12V, +24V
WBV332U05-S脉动直流DC 10mV, 10V, 100V, 500V, 1000VDC 0~5V, 0~10VDC +12V, +24V
WBV334U01-S脉动直流DC 10mV, 10V, 100V, 500V, 1000VDC 0~20mA, 4~20mADC +12V, +24V
WBV334U05-S脉动直流DC 10mV, 10V, 100V, 500V, 1000VDC 0~20mA, 4~20mADC +12V, +24V
WBV132G31直流DC 50mV~1V, 大于 1V可外配电阻至1000VDC 3V, DC3.5V, DC5V, DC10VDC +5V, +12V, +15V, +24V
WBV141G31直流DC 50mV~1V, 大于 1V可外配电阻至1000VDC 3V, DC3.5V, DC5V, DC10VDC +5V, +12V, +15V, +24V
WBV151G31直流DC 50mV~1V, 大于 1V可外配电阻至1000VDC 1.25V±1.25V, DC2.5V±2.5V, DC5V±5VDC +5V, +12V, +15V, +24V
WBV151S01双向直流DC 50mV,75mV, 30V, 50V, 100V, 500VDC 2.5V±2.5V, 5V±5VDC +12V, +15V, +24V
WBV153S01双向直流DC 50mV,75mV, 30V, 50V, 100V, 500VDC 12mA±8mA, 10mA±10mADC+12V, +15V, +24V
WBV342H29直流DC 10mV, 10V, 100V, 500V, 1000VDC 0~20mA, 4~20mAAC 85V~265V或DC 100V~360V
WBV344H29直流DC 10mV, 10V, 100V, 500V, 1000VDC 0~20mA, 4~20mAAC/DC 85V~265V
WBV332H29脉动直流DC 10mV, 10V, 100V, 500V, 1000VDC 0~20mA, 4~20mAAC 85V~265V或DC 100V~360V
WBV334H29脉动直流DC 10mV, 10V, 100V, 500V, 1000VDC 0~20mA, 4~20mAAC/DC 85V~265V
WBV142G21DC 50mV~1V, 可外配电阻至1000VDC 0~5VDC +12V, +15V, +24V
WBV144H21-ASDC 10mV, 70VDC 4~20mADC +12V, +24V
WBV344M05DC 10mV, 10V, 100V, 500V, 1000VDC 0~20mA, 4~20mADC 9V~36V
WBV351M05DC ±10mV, ±10V, ±100V, ±500V, ±1000VDC ±5V, ±10VDC 9V~36V

交直流电压传感器（通用型）

型号输入输出电源
WBV121G37AC/DC 50mV~1V, 大于 1V可外配电阻至1000VAC/DC 3.5V, 0~5VDC ±12V, ±15V
WBV121S07AC/DC 75mV, 30V, 50V, 100V, 500VAC/DC 3.5V, 5VDC ±12V, ±15V
WBV122S01AC/DC 75mV, 30V, 50V, 100V, 500VDC 0~5V, 0~10VDC +12V, +24V
WBV124S01AC/DC 75mV, 30V, 50V, 100V, 500VDC 0~20mA, 4~20mADC +12V, +24V
WBV124S01-1AC/DC 75mV, 30V, 50V, 100V, 500VDC 0~20mA, 4~20mADC +12V, +24V
WBV125S01AC/DC 75mV, 30V, 50V, 100V, 500VDC 0~5V, 0~10VDC +12V, +24V
WBV127S01AC/DC 75mV, 30V, 50V, 100V, 500VDC 0~20mA, 4~20mADC +12V, +24V
WBV121M05AC/DC 50mV, 30V, 50V, 100V, 500VAC/DC 3.5V, 5V;DC ±10V(仅当输入为直流时);DC 9V~36V

霍尔电压传感器

型号输入输出电源
WBV023YB08-DD1000V~3000V50mA+24V
WBV023YB08-SS1000V~3000V50mA±12V, ±15V
WBV023TK08-SS100V~4000V50mA±12V, ±15V

直流高隔离传感器

型号输入输出电源
WB9163-1DC ±100V~DC ±2200VDC ±20mA,DC 12mA±8mA,DC ±5V,DC ±10V,DC 5V±5VDC +24V
DC 100V~DC 2200VDC 5V, DC 10V, DC 20mADC +24V
WB9163-2DC ±50mV, ±60mV, ±70mV, ±75mV(特殊可定制)DC ±5V,DC  ±10V,DC ±5V,DC ±20mA,DC 12mA±8mADC +12V, +24V
WB9163 -3DC ±30mV~DC±100VDC ±20mA,DC 12mA ±8mA,DC ±5V,DC ±10V,DC 5V±5VDC +24V
DC 30mV~ DC100VDC 5V, DC 10V, DC 20mADC +24V

D. 频率传感器

频率传感器

型号输入输出电源
WBF152H2540Hz~60Hz/45Hz~55Hz (50V~500V)DC 0~5V, 0~10VDC +12V, +24V
WBF152H2940Hz~60Hz/45Hz~55Hz (50V~500V)DC 0~5V, 0~10VAC/DC 85V~265V
WBF154H2540Hz~60Hz/45Hz~55Hz (50V~500V)DC 0~20mA, 4~20mADC +12V, +24V
WBF154H2940Hz~60Hz/45Hz~55Hz (50V~500V)DC 0~20mA, 4~20mAAC/DC 85V~265V

E. 功率传感器

功率传感器

型号输入输出电源
WBC111S91-0AC 10V~500V, AC 5A~50ADC 2.5V±2.5VDC +12V, +24V
WBP111S91AC 10V~500V, AC 5A~50ADC 2.5V±2.5VDC +12V, +24V
WBP112S91AC 10V~500V, AC 5A~50ADC 0~5VDC +12V, +24V
WBP114S91AC 10V~500V, AC 5A~50ADC 0~20mA, 4~20mADC +12V, +24V
WB9128-1相电压AC 57.7V~289V, 线电压AC 100V~500V, AC 1A~50ADC 0~20mA, 4~20mA;DC0~5V, 1~5V;DC 2.5V±2.5V, 3V±2V；DC +12V, +24V
WB9128-5线电压AC 660V, AC 1A~50ADC 12mA±8mA, 10mA±10mADC +12V, +24V

F. 标准信号调理器/配电器

调理器

型号输入输出电源
WBT1C1CS03一路4~20mA一路4~20mADC +12V, +24V
WBT1C1CU05一路4~20mA一路4~20mADC +24V
WBT1C4CU05一路4~20mA两路4~20mADC +24V
WBT2C4CU05两路4~20mA两路4~20mADC +24V

配电器

型号输入输出电源
WBT3C1CU05一路4~20mA一路4~20mADC +24V
WBT3C4CU05一路4~20mA两路4~20mADC +24V

G. 越限报管传感器

电流越限报警传感器

型号输入输出电源
WBK1I1KS41AC 0.5A, 1A, 2A……8ARkDC +12V,+24V
WBK1I1KS91AC 5A, 8A, 10A……50ARkDC +12V,+24V
WBK1I1DF61AC 30A, 50A, 80A……400ARdDC +12V,+24V
WBK4I1DU01DC 1mA, 5mA, 20mA……5ARdDC +12V,+24V

电压越限报警传感器

型号输入输出电源
WBK1V1DU01AC 10V, 50V, 100V……1000VRdDC +12V,+24V
WBK1V3DU01AC 10V, 50V, 100V……1000VRdDC +12V,+24V

H. 无源交流采样器

无源交流电流采样器

型号输入输出电源
WBCT41D401AC 2A, 5A……8AAC 1V-
WBCT43B402AC 2A, 5A……8A2000:1-
WBCT53C902aAC 20A~40A3000:1/2000:1-
WBCTB3C104bAC 100A2000:1-

无源交流电压采样器

型号输入输出电源
WBPT43B002AC 10V~1000V1mA-
WBPT43D001AC 10V~1000V1mA-
WBPT41D001AC 10V~1000V1V-
WBCP41E901AC 10V~1000V,AC 5A~30AAC 1V-

I. 智能电量传感器

单元式交流电参量传感器

型号输入输出电源
WB6830R2-PAC 10V~500V, AC 0.5A~5A全参数可测，带谐波含量，RS485总线DC +12V, +24V
WB6810H3AC 57.7V~600V, AC 10mA~1A~5A全参数可测，RS485总线DC +12V, +24V
WB6810H5AC 57.7V~600V, AC 1A~50A全参数可测，RS485总线DC +12V, +24V

组合式交流电参量传感器

型号输入输出电源
WB6410H3AC 57.7V~600VRS485总线DC +12V, +24V
WB6210H3AC 10mA~1A~5ARS485总线DC +12V, +24V
WB6210H5AC 1A~50ARS485总线DC +12V, +24V
WBI1800B35AC 10V~400VRS485总线DC +12V, +24V
WBI1801B35AC 0.5A~5ARS485总线DC +12V, +24V
WBI1802B35AC 10V~400VRS485总线DC +12V, +24V
WBI1803B35AC 0.5A~5ARS485总线DC +12V, +24V

组合式直流电参量传感器

型号输入输出电源
WB1925B35DC 0.5~5A, DC 75mV~700VRS485总线DC +12V, +24V
WB1926B35DC 75mV~700VRS485总线DC +12V, +24V
WB1929B35DC 75mV~700V（两路）RS485总线DC +12V, +24V
WB1927B35DC 0.5A~5ARS485总线DC +12V, +24V
WB1928B35DC 0.5A~5A（两路）RS485总线DC +12V, +24V

J. 新能源汽车传感器

电池巡检仪

型号输入输出电源
WB7660QB-24Z单体电池DC 2V、6V、12VRS485总线DC +12V~+24V

绝缘电阻监测模块

型号输入输出电源
WB9162电流: DC 2.5V±2V,(对应外置电流传感器-400ADC~+400ADC输入)；电压DC 0~750VUART，无校验，1个停止位，通信波特率9600BPS，通信地址1DC 5V±5%

直流电能表

型号输入输出电源
DJS5169电压:DC 0~750V;电流:DC 75mV（外配分流器）两路RS485DC +12V, +24V
DJS5119电压:DC 0~1000V;电流:DC 75mV (外配分流器)RS485DC 9V~36V
DJS5029DC 0V~1000V, 电流外配分流器（DC 75mV）RS485DC 9V~36V

三相电子式多回路电能表

型号输入输出电源
WB5163-DAC 0~500V, AC 0~100A （外配）RS485AC 85V~265V, DC 100V~360V

K. 智能电力监控仪表

多功能谐波仪表

型号输入输出电源
WB5110-DAC 0~500V, AC 0~5A段式LCD, RS485AC 85V~265V, DC 100V~360V

L. 配套产品

温度传感器

型号输入输出电源
WB41SN11-01PT100, PT1000, CU50DC 0~20mA, 4~20mADC +24V, AC 220V

水浸传感器

型号输入输出电源
WB40ZY03-3与水接触式RKDC +12V, +24V


COPYRIGHT (©) 2022 苏州金迈岑电子科技有限公司 苏ICP备17001829号-1

技术支持：万禾科技
